Features

  • Supports Warehouse & Logistics, Work Truck applications and other demanding environments
  • New function key option include screen rotation, screen blanking & cleaning
  • The coiled cable makes it easy to replace in the field
  • Full F1-F12 function keys for easy operation
  • Keyboard features 83 keys and integrated touchpad
  • Red monochrome illumination backlight for reduced eye strain
  • Silicone rubber keyboard for easy cleaning with a soft cloth and non-corrosive cleaning solvent
  • IP65 rated for demanding environments
  • Standard USB connection allows for connection to docking station or direct to computing device
  • Easily installed plug and play drivers
  • Integrated mounting features for use with Havis Rugged keyboard mount (C-KBM-201, not included)
  • Integrated VESA 75 mounting pattern

Specifications

PRODUCT SPECIFICATIONS:
Dimensions:7.73" high x 11.98" wide x 1.25" deep
Compatible Packages:PKG-KBM-1002
Mounting:VESA 75 and AMPS
Communication Interface:USB-A
Working Voltage:USB: 200mA@5V
Operating environment:-4 °F TO 158 °F (-20 °C TO +70 °C)
Storage environment:-4 °F TO 158 °F (-20 °C TO +70 °C)
Testing:Humidity, Shock, Vibration
Product weight:1.7 Lbs (0.80 Kg)
Gross weight:2.5 lbs

Resources

Owner's Manual
Owner's Manual
Work Truck Keyboard Sales Sheet
Work Truck Keyboard Sales Sheet
Warehousing & Logistics Keyboard Sales Sheet
Warehousing & Logistics Keyboard Sales Sheet

Application Gallery

Related products

FAQs

  • The Integrated Control System (ICS) will supported through June 2023; this system will be marked End of Service Life (EOSL) effective July 1, 2023.
  • All inquiries and requests for support can be directed to the Havis Technical Support Team at (800) 458-3410

If you would like to display Havis products in a showroom, demonstration vehicle, tradeshow display or similar area, please contact the Havis Sales Team to inquire.

Qualifying customers can test and evaluate products as part of the Test Drive Program. To submit an application to Test Drive a product, visit a product specification page and click Test this Product. After submitting your information, a Sales representative will contact you. Customers may also be interested in seeing a Havis demo vehicle in person. Check out our Find a Demo Unit page for more information.

Havis has elected to Go Green and will no longer be printing MSRP Price Booklets due to the fact that they are instantly outdated. However, our website is updated every day with the most accurate product information as well as many enhanced features. Product pricing can be found on each product specification page.

Havis has elected to Go Green and will no longer be printing catalogs due to the fact that they are instantly outdated. However, our website is updated every day with the most accurate product information as well as many enhanced features.

Electronic versions of Havis literature are available on the Havis Literature page.

Havis will provide literature to support Preferred Resellers. Please contact us, and enter your specific request under Questions/Comments.

In many cases, products are easily transferable between old and new vehicles. However, product transferability does depend on many variables including vehicle year/make/model, other equipment, etc. For more information, please contact Havis Sales Team.

Sales and Technical Support try to respond to all installation questions as quickly as possible. You should hear back within 24 hours of your request.

No, Havis does not have authorized installers nationwide. However, many Havis Resellers offer installation services and would be willing to work with you. To locate a reseller in your area, please use our interactive reseller map.

Havis does provide installation services to local customers near the Warminster, PA location. Please contact the Havis Sales Team to inquire.

Many Havis Resellers offer installation services and would be willing to work with you. To locate a reseller in your area, please use our interactive reseller map.

If you need installation help, please contact our Sales department by calling 1.800.524.9900 or by contacting us online. If Sales is unable to answer your question, they will direct you to the appropriate Technical Support representative to assist with your installation.

Product assembly varies between each specific product. Installation instructions are provided with your shipment for each product and on each product specification page online.
