Features

  • VSS Series Current Sensor is designed to operate in the most severe enviroments
  • High Strength Glass Filled Polycarbonate housing
  • Mount with #10 or M5 hardware
  • DC Cable opening for up to 4/0 awg and 4/0 lug
  • Sensitivity at 5V supply is 23.75 and 3.17 mV/A
  • Required mating Deutsch connection
  • 18 months warranty

PRODUCT SPECIFICATIONS:
DC Input:Supply Voltage: 4.5-5.5 V
DC Voltage Range:Supply Current: 25 mA
Operating Temperature:-40F to 125F (-40C to 52C)
Surge Rating:Load Resistence is: 10kΩ
Dimensions:1.25”H x 4.5”W x 2.9”D
Product Weight:< 1.0 lbs
Gross weight:0 lbs

Resources

Owner's Manual
Owner's Manual
